Underwater Ultrasound Cleaning System Submersible Ultrasonic Transducer Generator

Product Features

The ultrasonic vibration plate made of special technology and materials has the characteristics of high stability and long service life, as follows:

Specially designed and meticulously crafted vibration plates, using high Q-value ultrasonic power for strong and long-lasting performance.
There is no concern of degumming, making the transmission path of sound waves unobstructed.
It is resistant to high temperature, corrosion, and enables the vibration plate to work stably for a long time in boiling water at 100 ℃.
After cleaning, careful maintenance and upkeep can prolong the service life of the vibration plate, with an average working life of at least 5 years.

Type	Diamention(mm)	Frequency (Khz)	Power(W)	Ultrasonic Transducer
PU-UITP300W	300190100	25,28,33,40,80,130	300	6
PU-UITP600W	360275100	25,28,33,40,80,130	600	12
PU-UITP1000W	450350100	25,28,33,40,80,130	1000	20
PU-UITP1200W	470380100	25,28,33,40,80,130	1200	24
PU-UITP1500W	520450100	25,28,33,40,80,130	1500	30
PU-UITP1800W	560450100	25,28,33,40,80,130	1800	36
PU-UITP2000W	650450100	25,28,33,40,80,130	2000	40
PU-UITP2400W	740520100	25,28,33,40,80,130	2400	48
PU-UITP3000W	820540100	25,28,33,40,80,130	3000	60
PU-UITP5000W	1200590100	25,28,33,40,80,130	5000	100
OEM Ultrasonic Immersible Transducer Pack（Size, Frequency,Power）

Underwater Ultrasound Cleaning System Submersible Ultrasonic Transducer Generator

标签：Submersible Ultrasonic Transducer Generator, Underwater Ultrasound Cleaning System
