![High Power Ultrasonic Handheld portable Spot Welder Plastic Ultrasonic Welding Gun Easy Operation And Sound Generator](https://www.desktopultrasoniccleaner.com/wp-content/uploads/2023/07/2023071411030793.jpg)
High Power Ultrasonic Handheld portable Spot Welder Plastic Ultrasonic Welding Gun Easy Operation And Sound Generator
Operation method of ultrasonic spot welding machine: Firstly, connect the ultrasonic output plug, connect the 220V power supply after plugging in the power plug, turn on the power switch (the power indicator light is on), and adjust the panel time according to the product requirements. Pick up the handle and press…
Operation method of ultrasonic spot welding machine:
Firstly, connect the ultrasonic output plug, connect the 220V power supply after plugging in the power plug, turn on the power switch (the power indicator light is on), and adjust the panel time according to the product requirements. Pick up the handle and press the handle button to check whether the ultrasonic wave is normal {The Ammeter on the panel is normal at 0.5A in no-load}.
Start working:
When operating the product, hold the ultrasonic handle vertically and place it on top of the product. Apply a point of force while pressing the handle button. At this time, the ultrasonic wave is emitted and the product welding is completed by the set time. After the production task is completed, turn off the power supply.
Type | power (W) | Frequency | Welding time | Contains |
PU-HH300W | 300W | 20khz,28khz,30khz,35khz,40khz | 0.1-3sec | generator , transducer ,horn,head |
PU-HH500W | 500W | 20khz,28khz,30khz | 0.1-3sec | generator , transducer ,horn,head |
PU-HH900W | 900W | 20khz,28khz,30khz | 0.1-3sec | generator , transducer ,horn,head |
PU-HH1000W | 1000W | 20khz,28khz | 0.1-3sec | generator , transducer ,horn,head |
PU-HH1200W | 1200W | 20khz,28khz | 0.1-3sec | generator , transducer ,horn,head |
标签:High Power Ultrasonic Handheld portable Spot Welder, Plastic Ultrasonic Welding Gun Easy Operation And Sound Generator
